The Sysmex CA-104 analyser is your straight-forward, compact semi-automated coagulation system designed to simplify coagulation testing; making it more standardised and reproducible. Together with the same high-quality reagents used on the fully automated coagulation analysers, Sysmex CA-104 analyser provides a reliable and affordable solution for small testing facilities.

CA-104

Small, easy to-handle four-channel semi-automated coagulation analyser, utilising photo-optical turbodensitometric detection principle for analysing routine clotting tests such as PT, APTT, TT, Fbg and single factor.

Registered Under Act 737 (IVDA1335722-87555)

The Sysmex CA-104 analyser offers an economical, convenient, safe and secure, semi-automated coagulation analyser to standardise your essential haemostasis testing.

Economical

  • Utilises half-volume of plasma and reagent as compared to manual tilt-tube method.
  • Single cuvette testing.

Convenient

  • Simple operation.
  • Easy-to-use pre-programmed methods & on-screen prompts.
  • Automatic calculation of results.

Safe and secure

  • Built-in pre-incubation timer.
  • Auto-start and timing of measuring process.
  • Temperature controlled incubation block for reagents and samples.
  • Built-in thermal printer.
  • Calibration curves stored onboard.
  • PT: Dade Innovin, Thromborel S
  • APTT: Dade Actin, Dade Actin FS, Dade Actin FSL, Pathromtin SL
  • Fibrinogen: Multifibren U
  • Thrombin Time: Test Thrombin, Thromboclotin
  • Factor Deficiency: Factor II, V, VII, VIII, IX, X, XI, XII
Detection principles Clotting: turbodensitometric photo-optical measuring principle
Detection channel/method 4 LEDs with wavelength 870 nm for clotting assays
Parameters 1 simultaneous analysis parameter
Sampling Manual pipetting, auto-start function
Reagent holder 4 positions at 37°C (1 with reagent mixer)
1 position at room temperature
Reference curves Manual input of reference curve (up to nine points)
Printer Built-in thermal printer
Dimensions (WxHxD)/weights 270 x 95 x 310 mm, 2.9 kg (without AC adaptor)

Download CA-104 brochure here

Download CA-104 Specs sheet here

Features & Benefits

The Sysmex CA-104 analyser offers an economical, convenient, safe and secure, semi-automated coagulation analyser to standardise your essential haemostasis testing.

Economical

  • Utilises half-volume of plasma and reagent as compared to manual tilt-tube method.
  • Single cuvette testing.

Convenient

  • Simple operation.
  • Easy-to-use pre-programmed methods & on-screen prompts.
  • Automatic calculation of results.

Safe and secure

  • Built-in pre-incubation timer.
  • Auto-start and timing of measuring process.
  • Temperature controlled incubation block for reagents and samples.
  • Built-in thermal printer.
  • Calibration curves stored onboard.
Assay
  • PT: Dade Innovin, Thromborel S
  • APTT: Dade Actin, Dade Actin FS, Dade Actin FSL, Pathromtin SL
  • Fibrinogen: Multifibren U
  • Thrombin Time: Test Thrombin, Thromboclotin
  • Factor Deficiency: Factor II, V, VII, VIII, IX, X, XI, XII
Specifications
Detection principles Clotting: turbodensitometric photo-optical measuring principle
Detection channel/method 4 LEDs with wavelength 870 nm for clotting assays
Parameters 1 simultaneous analysis parameter
Sampling Manual pipetting, auto-start function
Reagent holder 4 positions at 37°C (1 with reagent mixer)
1 position at room temperature
Reference curves Manual input of reference curve (up to nine points)
Printer Built-in thermal printer
Dimensions (WxHxD)/weights 270 x 95 x 310 mm, 2.9 kg (without AC adaptor)
